LA39-E series pushbuttons are featured as clever design, good visual appearance, and exquisite body, simple and easy installation as well as reliable contact. They are the best choice for the users requiring miniaturized and intensive control of the panel.

Rated Insulation voltage is AC 250V (50Hz). Conventional thermal current is 5A. Mechanical Endurance: 10×10ˆ4 times. Electrical Endurance: 10×10ˆ5 times (AC-15), 5×10ˆ5 times (DC-13).

Contacts resistance < 50mΩ. IP40

Packaging & Delivery

Standard packing quantity: 20 PCS.

Delivery is 5 work days.

Package Includes:

• Plastic keyed safety switch Rectangle key switch on off
